Front
1 | Feed Dog Up/Down | 2 | Needle Area |
3 | Connection for Embroidery Module | 4 | Lighting |
5 | Thread Cutter | 6 | Thread Take-up Lever |
7 | Connection for Slide-on Table | 8 | Connection for Sewing Table |
Needle Area
1 | Bobbin Cover | 2 | Stitch Plate |
3 | Feed Dog | 4 | Presser Foot |
5 | Needle | 6 | Buttonhole Lever |
7 | Needle Holder | 8 | Needle Threader |
9 | Stitch Plate Release Button |
Sewing table and accessory box
1 | Sewing Table | 2 | Accessories Box |
3 | Accessories Box Cover |
