Changing the Needle

The use of the needle inserter is recommended and prevents the needle from falling into the feed dog area.Accessories storage with accessories

Correctly inserted needles are not at the same height.

The needle holder screws must always be tightened, even if no needles are inserted. This prevents the needle holding screws from falling out because of vibrations.

NOTICE

Damage due to Excessive Tightening of the Screws

The threads of the needle holder may be damaged. A repair by the authorized bernette dealer is required.

  1. Do not overtighten the needle screws.

    Prerequisite:

  1. The needles are in the top position.
  2. The presser foot is raised.
  1. Hold the needle and loosen the needle screw from the threader cover using the screwdriver supplied.
  3. Remove the needle downwards and store it in the needle pad.
  4. Insert the new needle with the flat side to the back into the needle inserter.
  6. Push the needle into the corresponding needle holder opening as far as it will go.
  7. Check the needle position in the needle checking window.
  8. Tighten the needle screws.
